• JBC原装RMSE-2D三合一返修工作站焊台 产品型号:RMSE-2D RMSE-2D成套返修工作站, 带电动马达
    包含JTSE热风 T245焊接 DR560吸锡三种模式,适应各种返修工作
产品介绍
技术参数

产品描述:

· DDE-B 和 JTSE-A 控制主机

· AD-SD, DR-SD 和 JT-SD 工具座

· T245-A 通用型 和 DR560-A 吸锡手柄

· JT-T2A 加热软管套装

· T260-A 取放笔

· C245-903 和 C245-906 烙铁头

· C560-004, C560-005 和 C560-013 吸锡嘴

· MSE-A 电动拆焊模组

· CL6166 焊嘴清洁座

· 其他配件

· * 磁吸配件盒包括3个磁吸杆,5个保护罩和 2个三脚架

使用 C245 系列烙铁头,

C560 吸锡嘴系列 and JN 热风嘴

Complete Rework station with Electric Pump

RMSE-1D/ RMSE-2D / RMSE-9D

- Total weight: 16.6 kg (36.6 lb)

- Ambient Operating Temperature: 10 to 40ºC (50-104ºF)

JTSE-1D 120V 50/60Hz. Input fuse 8A. Rated current: 6A.

JTSE-2D 230V 50/60Hz. Input fuse 4A. Rated current: 3A.

JTSE-9D 100V 50/60Hz. Input fuse 8A. Rated current: 7A.

- Weight: 3.9 kg (8.5 lb)

- Dimensions: 148 x 184 x 140

- Nominal Power: 700W

- Temperature selection: Room temperature / 150ºC to 450°C (300ºF to 840ºF)

Cool mode: T Off. Used to blow air at room temperature

- Ambient Operating Temperature: 10 to 40ºC (50-104ºF)

- Air flow regulation: 10-50 SLPM

- Vacuum: 30% / 228 mmHg / 9 inHg

- USB connector station-PC

- P-005 Pedal Connection

DDE-1B 120V 50/60Hz. Input fuse: 4A. Output: 23.5V

DDE-2B 230V 50/60Hz. Input fuse: 2A. Output: 23.5V

DDE-9B 100V 50/60Hz. Input fuse: 5A. Output: 23.5V

- Weight: 4.3 Kg (9.3 lb)

- Dimensions: 148 x 120 x 232 mm

- Output Peak Power: 150W per tool

- Temperature Range: 90-450°C (190-840 ºF)

- Idle Temp. Stability (still air) ±1.5 ºC (±3 ºF)

- Tip to ground resistance: <2 ohms

- Tip to ground voltage: <2mV RMS

- USB-A / USB-B / Peripherals connectors

- RJ12 connector for Robot

MSE-A

- Weight: 1.2 Kg (2.6 lb)

- Dimensions: 145 x 55 x 225 mm

- Vacuum: 75% / 570 mmHg / 22.4 inHg

- Flow rate: 9 SLPM

- P-005 Pedal connection
